Tenda HG3 XPon Fiber Router

Description

• Hardware
  IEEE Standards

  IEEE 802, 802.1Q, 802.10, IEEE 802.11, 802.3U, 802.3Z

  PON Standards

  GPON: ITU G.984.1, ITU G.984.2, ITU G.984.3, ITU G.984.4
  EPON: IEEE802.3ah

  Interfaces

  1*SC/APC (or UPC) Port
  1*1000Mbps RJ45 LAN Port, 1*100Mbps RJ45
  LAN Port, 1*DC Port

  LED Indicator

  1*WPS/RST Button

  Button

  1*WPS/RST Button

  Optical Mode

  Class B+

  Optical Wavelength

  Transmit at 1310nm, Receive at 1490nm

  Transmission Distance

  20km Max

  Bandwidth

  Upstream 1.25Gbps Max, Downstream 2.5Gbps Max

  Dimension

  166.6*90.5*27mm (W * D * H)

  TX Power

  0.5~5dBm

  RX Power

  -28~-8dBm

  External Power Supply

  DC 9V /1A

  Power Consumption

  ≤9w

• Software
  DHCP Server

  PPPOE, Dynamic IP, Static IP, Bridge, Support Multiple WAN Connection

  WAN Connection

  PPPOE, Dynamic IP, Static IP, Bridge, Support Multiple WAN Connection

  Business Type

  TR069, Internet, IPTV

  Quality Of Service

  Bandwidth Control

  IP Version

  IPv4, IPv6

  Services

  DHCP, Dynamic DNS , IGMP Proxy UPnP

  VPN Pass-through

  PPTP, L2TP, IPsec Pass-through

  Firewall

  ALG, IP Filter ,Port Filter, Mac Filter, URL Filter Port Forwarding, DMZ

  IPv6

  Radvd, DHCPv6, MLD Proxy, MLD Snooping

  Diagnostics

  Ping, Ping6, Tracert, Tracert6

  TR069

  ACS, Connection request
